Technical Features
- Full Charge time Standard 80min, Full charge at 1 hour possible
- Standard Charge Current 0.5C
- Maximum Charge Current 1C
- Opportunity Charge Current 0.75C
- Max. Continuous Discharge Current 1C
- Temperature during charge 0°C up to 45°C (32°F up to 113°F)
- Temperature during discharge -20°C up to 55°C (-4°F up to 131°F)
- Nominal battery voltage range 25.6V – 38.4V – 51.2V – 83.2V
- Available Capacities up to 864Ah
- Tray Sizes (Dimensions, weights) DIN, BS, Customized
- State of Charge indicator Integrated on the battery
- Communication Protocol CAN bus
- Intercell connections Copper Nickel-plated connectors
- Electrical Power Connection REMA, Anderson
SUNLIGHT Li.ON FORCE Charger series advantages:
- Innovative and worldwide unique multi-resonance converter technology
- High Energy Efficiency up to 97%
- IU charging characteristic
- Fast and opportunity charging modes
- Able to achieve full recharge of the battery within 1 hour
- IP21, higher protection categories up to IP54 upon request
- Fixed connections – ready to “plug & charge”
- Small footprint – decentralized charging point installed in the area where the vehicle operates
- Touch graphic display
- Integrated CAN interface with established data transfer and communication with Li.ON FORCE BMS offering fully-controlled, advanced charging procedure
| Characteristics | Lead Acid Batteries | Li.ON FORCE Batteries |
|---|---|---|
| Energy Density | ~ 100 Wh/L | 233 Wh/L |
| Charging Efficiency | Up to 80% | Up to 95% |
| Emissions | Environmental unfriendly / Gassing and water loss when charging | Environmental friendly / Emission free |
| Maintenance | Required / water filling – check points | Not required |
| Charging Time (Full Charging) | 8h | ~ 1 – 1.5h |
| Opportunity Charging | Negative effect on service life | Yes, with NO negative effect on service life |
| Energy Efficiency | Up to 80% | 95% |
| Operating Temperature | -20°C up to 55°C (-4°F up to 131°F) | -20°C up to 55°C (-4°F up to 131°F) |
| Temperature during Charge | -10°C up to 55°C (14°F up to 131°F) | 0°C up to 45°C (32°F up to 113°F) |
